EP · 2.5 tonne · lithium
The all-round 2.5 tonne that most Melbourne warehouses actually need.
The 60A charger requires a three-phase supply. Battery is modular — expandable to a dual 560Ah pack for multi-shift work.
Indicative from-rates, ex GST, for approved commercial credit on a 36-month fully maintained term. Every price shown is a starting point, not a fixed offer — your written quote reflects site assessment, annual hours, configuration, delivery zone and credit assessment, and may be higher where risk factors apply. Reviewed August 2026.
KEY SPECIFICATIONS
- Rated capacity
- 2,500 kg
- Mast
- 4.5 m triplex
- Full free lift
- No
- Battery
- 80V / 280Ah lithium (≈22.4 kWh)
- Charger
- 80V/60A charger (three-phase)
- Site power needed
- Three-phase supply
- Tyres
- Solid tyres
- Attachments
- Side shift, 4-spool valve, LED work + warning lights, OPSS, 1070 mm tynes
Right machine if…
- General warehousing, manufacturing, beverage, timber and building supplies
- Regular loads between 1.5 t and 2.5 t
- Mixed indoor and sealed-yard work
- Businesses that may add a second shift later (dual-battery option)
Wrong machine if…
- Sites without three-phase power
- Container work needing full free lift (choose the BYD EL25-Pro)
- Loads regularly above 2.5 t (choose the EFX5-351)
Why sites pick the EFX5-251
- 16 kW AC drive — up to ~17 km/h travel speed
- Modular battery: field-expandable to 560Ah
- AC Zapi controller with 1-year fleet-management subscription
Rated capacity applies at a 500 mm load centre at low height. Residual capacity reduces with lift height, long loads and attachments — we verify the manufacturer load chart against your heaviest pallet and top beam height before recommending any machine.
Full technical specifications
EP EFX5 series official brochure (PDF)OUR HIRE CONFIGURATION
- Mast
- 4.5 m triplex
- Battery
- 80V / 280Ah lithium (≈22.4 kWh), modular
- Charger
- 80V/60A, three-phase supply (manufacturer lists 60A as on-board; dealer quote sheet lists external — confirmed at delivery)
- Attachments
- Side shift · 4-spool valve · 1070 mm tynes · solid tyres · OPSS · LED · fleet management (1 yr)
CAPACITY & WEIGHTS
- Rated capacity
- 2,500 kg @ 500 mm load centre
- Service weight
- 3,835 kg ⁱ
- Axle load laden, front/rear
- 5,679 / 656 kg ⁱ
- Wheelbase
- 1,685 mm
DIMENSIONS
- Overall width
- 1,154 mm
- Length to fork face
- 2,520 mm
- Turning radius (Wa)
- 2,270 mm
- Ground clearance
- 150 mm
- Mast lowered height (4.5 m 3-free mast)
- 2,160 mm
- Mast extended height (4.5 m mast)
- 5,280–5,595 mm
- Free lift (4.5 m 3-free mast)
- 1,135–1,450 mm
- Fork dimensions
- 122 × 40 × 1,070 mm
PERFORMANCE
- Travel speed, laden/unladen
- 16 / 17 km/h
- Lift speed, laden/unladen
- 0.38 / 0.45 m/s
- Lowering speed, laden/unladen
- 0.45 / 0.52 m/s
- Max gradeability, laden/unladen
- 17% / 25%
DRIVE & BATTERY
- Motors
- 16 kW drive (S2 60 min) · 24 kW lift (S3 15%) · Zapi controller
- Modular battery
- 1× 280Ah standard — field-expandable to 2× 280Ah (560Ah) for multi-shift
- Charger options
- 35A/60A on-board · 65A/100A/150A/200A external (200A requires dual 280Ah battery)
Figures marked ⁱ are manufacturer standard-configuration values from the official brochure; hire machines are delivered in the configuration listed under “Our hire configuration”. The load chart fitted to the delivered machine always governs capacity at height and with attachments.
See it working
Official manufacturer footage of the EFX5-251 platform — the machine itself, not marketing renders.
X5 series is here — Electric counterbalance 3000–3800 kg (official)
2.5T Li-ion forklift — EP EFX 251 (official) Videos play from YouTube's cookie-free domain and load only when you press play.
Questions we get about the EFX5-251
Why choose the EFX5-251 over the BYD EL25-Pro?
The EFX5-251 has stronger drive performance (16 kW, ~17 km/h) and a lower weekly rate. The EL25-Pro answers a different job: 4.8 m full free lift for containers and high racking, plus 100A fast charging. If you do not need FFL or fast charging, the EFX5-251 is usually the better-value 2.5 t.
Can it work a double shift?
The standard 280Ah pack suits a full single shift. For double shifts the battery is modular and can be expanded to 560Ah, or you can use lithium opportunity charging during breaks — we size this against your actual hours during the fit assessment.
What power supply do I need?
The external 60A charger requires a three-phase outlet. If your site only has single-phase power, ask us about the EFL181 or a site power assessment.
Is the EFX5-251 right for your site?
Send us your loads, lift heights and power supply — we’ll confirm the load chart and quote it the same day.
